CNP vs. CNC Fit Testing: The Differences You Need To Know

April 8, 2026

Quantitative respirator fit testing comes down to two technologies: Controlled Negative Pressure (CNP) and Condensation Nuclei Counting (CNC). Both are OSHA and ISO-accepted. Both produce a fit factor. But how they get there, and how reliable that number is, differs more than most people realize.

There’s also a fair amount of misinformation out there about how CNP testing works. Some of it overstates CNC’s advantages. Some of it misrepresents what happens during a CNP fit test entirely.

Let’s set the record straight.

How CNP and CNC Fit Testing Methods Work

CNP creates a small, controlled negative pressure inside the respirator and measures how much air leaks in. The leak rate is the result. No particles, no ambient air dependency. The instrument creates the challenge, so every test subject gets the exact same challenge, every time.

CNC counts particles in the air outside and inside the respirator. The ratio between those two numbers produces the fit factor. The wearer’s breathing and movement generate the challenge by pulling particles through any gaps in the seal.

Both methods have strengths. But the differences matter when accuracy and consistency are the priority.

“CNP Subjects Don’t Move.” That’s Not True, Nor is it the Point.

With CNP, the machine creates the challenge. It doesn’t rely on the wearer’s movement or breathing to challenge the seal.

Here’s what actually happens during a CNP REDON protocol fit test:

Exercise 1: Facing forward. The subject stands still and holds their breath while the instrument takes a measurement. This is the baseline.

Exercise 2: Bending at the waist. The subject bends forward, letting gravity pull directly against the seal. If the respirator doesn’t fit well, gravity will create a gap. If it fits properly, the seal holds. After bending, the subject holds their breath while the instrument measures.

Exercise 3: Head shaking and talking. The subject shakes their head vigorously from side to side and talks out loud. This directly stresses the seal through dynamic facial movement. Then they hold their breath for measurement.

Exercise 4: First re-don. The subject removes the respirator completely, loosens all straps, and puts it back on without help from the test administrator. Then another measurement.

Exercise 5: Second re-don. They do it again. Remove, loosen, re-don, measure.

The breath hold during each measurement lasts about 10 seconds. The exercises between measurements are physical, dynamic, and specifically designed to challenge the seal.

Why Re-Donning Is the Test That Matters Most

Here’s something that doesn’t get talked about enough: research shows that how you put on a respirator affects fit more than what you do while wearing it.

Dr. Crutchfield’s 1999 study found that donning variability has a greater effect on measured fit than exercise variability. That’s a significant finding. It means a person might get a great seal one time and a poor seal the next, depending on how they don the respirator.

CNC protocols test a single donning. If the wearer happens to get a good seal that one time, they pass. But can they do it again tomorrow? Next week? In the field under pressure?

The CNP REDON protocol tests this directly. Three separate donnings during a single fit test. If you can’t consistently achieve a good seal, the test catches it.

CNP is the only fit testing technology that requires multiple donnings. That’s not a limitation. It’s a feature.

What the Research Says About Accuracy

The science here is clear, and it favors CNP for elastomeric respirators.

In a 1997 study, Crutchfield and Park introduced known, measurable leaks into respirators and tested them with both CNP and CNC systems. CNP detected 97.9% of the known leakage with a coefficient of variation of 4.3%.

CNP’s measurements were also unaffected by where the leak was located on the respirator. The CNC system’s results varied significantly depending on leak location.

CNC relies on counting particles inside the respirator, but particles deposit on interior surfaces and get inhaled by the wearer during the test. Those lost particles never reach the counter, which artificially inflates the fit factor. The fit looks better than it actually is.

CNP doesn’t have this problem. It measures airflow directly. Air doesn’t deposit on surfaces or disappear. What leaks in gets measured.

Why Fit Factors from CNP and CNC Aren’t the Same Number

If you test the same person in the same respirator with both methods, you’ll get different fit factors. That’s not a flaw. It’s because the two technologies calculate fit factors using entirely different formulas.

CNP calculates fit factor as the ratio of a modeled breathing rate to the measured leak rate (BR / LR). The breathing rate is fixed (for example, 53.8 L/min under the REDON protocol), so the result is anchored to a constant scale.

CNC calculates fit factor as the ratio of particle concentration outside the respirator to particle concentration inside (Cout / Cin). That ratio depends on ambient particle levels, which can vary during the test.

A fit factor of 500 from CNP is not the same measurement as a 500 from CNC. Both can represent an acceptable fit, but the numbers themselves can’t be directly compared across technologies. Each method has its own passing thresholds defined by OSHA and other standards.

What matters is whether each technology accurately and consistently measures the leakage it’s designed to detect. On that front, Crutchfield’s research is clear: CNP detected 97.9% of known leakage with minimal variation, while CNC detected 37.2% with high variation. Both are OSHA-accepted and validated, but CNP’s direct measurement of airflow gives it an edge in consistency and repeatability for elastomeric respirators.

When to Use Which

Neither technology is universally “better.” They serve different use cases, and their technologies are completely different.

Use CNP when:

You’re testing only elastomeric respirators (half-face, full-face, SCBA)

You need to test in any environment (CNP works anywhere air exists, no particles needed)

You want fast results with no consumables

You need to verify donning consistency across your workforce

Use CNC when:

You need to test disposable filtering facepieces (N95s)

You’re testing a mix of disposable and elastomeric respirators

Many organizations use both. CNP for their elastomeric program, CNC for disposables. That’s a smart, practical approach that gives organizations the best of both worlds.

The Bottom Line

CNP fit testing is not a static measurement taken on a motionless subject. The protocol includes bending, head shaking, talking, and multiple re-donnings, all designed to challenge the seal before each measurement.

The research shows CNP detects more leakage, produces more consistent results, and accurately tests the one variable that matters most in the real world: whether a worker can put on their respirator and get a proper seal, not just once, but every time.

Both CNP and CNC are OSHA-accepted and ISO-recognized quantitative fit testing methods. They’re both proven, both reliable, and both serve real needs in respiratory protection programs. The right choice depends on what you’re testing and what matters most to your program. OHD is the only company that offers both technologies, so we can help you find your best fit.

—

Ready to see CNP fit testing in action?  Learn more about QuantiFit2  or get a demo.

Looking to fit test both elastomerics and disposables? AeroFit is the best fit testing device for you! Get a demo or learn more about AeroFit.
